Enertech Global IOM, XT Models
Unit Physical Data
Dual Capacity Vertical
Model Number 024 036 048 060 072
Fan Wheel (in.) 10 x 11 10 x 11 10 x 11 10 x 11 10 x 11
Fan Motor ECM (HP) .5 .5 .75 1 1
Refrigerant Charge (oz.) 48 68 63 84 86
Air Coil
Face Area (Sq.Ft.) 5.55 5.55 5.55 6.17 6.17
Dimensions (in.) 31.8 x 25.1 x 1.0 35.9 x 24.7 x 1.26
Number Of Rows N/A - Micro-Channel Coil
Filter 1” Thick 28 x 30 x 1 28 x 34 x 1
Unit Weight (nominal) - lbs 395 400 450 455 460
Section 4: Unit Installation
Unit Electrical Data:
Model
Voltage
Code
60Hz Power Compressor
ECM
Fan
Motor
FLA
HWG
Pump
FLA
Ext
Loop
Pump
FLA*
Total
Unit
FLA
Min
Circuit
AMPS
Max
Fuse
HACR
Min
AWG
Max
Ft
Volts Phase LRA RLA
024
1 208/230 1 58.3 11.7 3.9 0.5 4.0 20.1 23.0 35 12 49
0 208/230 1 58.3 11.7 3.9 N/A N/A 15.6 18.5 30 14 41
2 208/230 3 55.4 6.5 3.9 N/A N/A 10.4 12.0 15 14 62
3 460 3 28.0 3.5 3.9 N/A N/A 7.4 8.4 10 14 87
036
1 208/230 1 83.0 15.3 3.9 0.5 4.0 23.7 27.5 40 10 70
0 208/230 1 83.0 15.3 3.9 N/A N/A 19.2 23.0 35 12 52
2 208/230 3 73.0 11.6 3.9 N/A N/A 15.5 18.4 30 14 41
3 460 3 38.0 5.7 3.9 N/A N/A 9.6 11.0 15 14 67
048
1 208/230 1 104.0 21.2 5.2 0.5 5.5 32.4 37.7 50 8 79
0 208/230 1 104.0 21.2 5.2 N/A N/A 26.4 31.7 50 8 97
2 208/230 3 83.1 14.0 5.2 N/A N/A 19.2 22.7 35 12 52
3 460 3 41.0 6.4 5.2 N/A N/A 11.6 13.2 20 14 55
060
1 208/230 1 152.9 27.1 6.9 0.5 5.5 40.0 46.8 70 6 102
0 208/230 1 152.9 27.1 6.9 N/A N/A 34.0 40.8 60 6 120
2 208/230 3 110.0 16.5 6.9 N/A N/A 23.4 27.5 40 10 71
3 460 3 52.0 7.2 6.9 N/A N/A 14.1 15.9 20 14 45
072
1 208/230 1 179.2 29.7 6.9 0.5 5.5 42.6 50.0 80 6 95
0 208/230 1 179.2 29.7 6.9 N/A N/A 36.6 44.0 70 6 111
2 208/230 3 136.0 17.6 6.9 N/A N/A 24.5 28.9 45 10 68
3 460 3 66.1 8.5 6.9 N/A N/A 15.4 17.5 25 14 41
Notes:
1. All line and low voltage wiring must adhere to the National Electrical Code and local codes, whichever is the most stringent.
2. Wire length based on a one way measurement with a 2% voltage drop.
3. Wire size based on 60°C copper conductor and minimum circuit ampacity.
3. All fuses class RK-5.
4. Min/Max Voltage: 208/230/60/1 = 187-252, 208/230/60/3 = 187-252, 460/60/3 = 432-504
5. See Example Electrical Circuits for proper 460V power
* The external loop pump FLA is based on a maximum of three UP26-116F-230V pumps (1/2hp) for 048 - 072 and two pumps for 024 - 036.
