EnGenius ECB-3220 - Appendices; Technical Specifications

11g Wireless Client Bridge/AP Version 1.36
50
Appendix A – Specifications
Data Rates
1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54
Mbps
Standards
IEEE802.11b/g, IEEE802.1x, IEEE802.3,
IEEE802.3u
Compatibility
IEEE 802.11g/ IEEE 802.11b
Power Requirements
Power Supply: 90 to 240 VDC ± 10％
(depends on different countries)
Device: 12 V/ 1A
Status LEDs
LAN: Link, WLAN: Link, Power: on/off
Regulation Certifications
FCC Part 15/UL, ETSI 300/328/CE
RF Information
Frequency Band
2.400～2.484 GHz
Media Access Protocol
Carrier Sense Multiple Access with
Collision Avoidance (CSMA/CA)
Modulation Technology
Orthogonal Frequency Division
Multiplexing (OFDM)
DBPSK @ 1Mbps
DQPSK @2Mbps
CCK @ 5.5 & 11Mbps
BPSK @ 6 and 9 Mbps
QPSK @ 12 and 18 Mbps
16-QAM @ 24 and 36 Mbps
64-QAM @ 48 and 54 Mbps
Operating Channels
11 for North America, 14 for Japan, 13 for
Europe,
Receive Sensitivity (Typical)
-88dBm @ 6Mbps
-70dBm @ 54Mbps
Available Transmit Power (Max.)
26dBm @ 1~24Mbps
23dBm @ 36Mbps
21dBm @ 48Mbps
20dBm @ 54Mbps
RF Connector
TNC Type (Female Reverse)
Networking
Topology
Ad-Hoc, Infrastructure
Operation Mode
Point-to-Point/ Point-to-Multipoint Bridge/
AP/ Client Bridge/ WDS
Interface
One 10/100Mbps RJ-45 LAN Port
Security
IEEE802.1x Authenticator / RADIUS Client
(EAP-MD5/TLS/TTLS) Support in AP
Mode
WPA2/WPA / Pre-share Key (PSK)/
AES/TKIP
MAC address filtering
Hide SSID in beacons
IP Auto-configuration
DHCP client/server
Management
Configuration
Web-based configuration (HTTP)
Firmware Upgrade
Upgrade firmware via web-browser
Environmental
Temperature Range
Operating: 0°C to 45°C (32°F to 113°F)
Storage: -20°Cto 70°C (-4°F to 158°F)
Humidity (non-condensing)
5%~95% Typical
