EnGenius EP800 - Zoned Network Receiver Signal Strength; Attenuate Receiver Signal Strength

DocNo.FM0805issueAPage32
39.ZONEDNETWORKRECEIVERRSSIPRINT‐OUTENABLE/DISABLE

ThezonednetworkreceiverRSSIvaluescanbeprintedforeveryradiodeviceactivation.ThisisanEngineersfunctionforuseduring
installationofzonedradiopendantsandshouldbeturnedofftosavepaperwhenrangetestingiscomplete.

RSSIPRINT‐OUTENABLE/DISABLE:

1.PresstheTALKkeyandenter81
2.Waitforthe“Ready”promptintheearpiece
3.Enterthecode7004followedbythekey
4.RadiodeviceRSSIprint‐outenabled/disabledwillbeheardintheearpiece
5.Pressthe#keytotogglebetweenenabled/disabled–thenewmodewillbeheardintheearpiece
6.PresstheENDkeytoclearthe connection




AnyzonednetworkreceiversthathavehadtheirRSSIvaluechangedusingthe1060  telephonecodewillbe
identifiedontheprint‐outbya*infrontofthereceivedpowerlevele.g.RP*064ZONE02





40.ZONEDNETWORKRECEIVERSIGNALSTRENGTHSET‐UP

Networkreceiverscanhavetheirsignalstrengthreducedifradiopendantsarebeingpicked‐upwithsimilarpowerinneighbouring
zonestherebygivinginaccuratecalllocation.ThisisanEngineersfunctionforuseduringinstallationandtestingonly.

ATTENUATEZONEDNETWORKRECEIVERSIGNALSTRENGTH:

1.PresstheTALKkeyandenter81
2.Waitforthe“Ready”promptintheearpiece
3.Enterthecode1060followedbythekey
4.EnterthezonenumbertohaveitsRSSIvalueattenuatedfollowedbythekey
5.Amessagewillannouncethecurrentattenuationvalue(zero=noattenuation)
6.IfthesettingisOKpresstheENDkeyorenteranewattenuationvalue
7.Pressthekeytoconfirmanda messagewillannouncethenewattenuationvalue
8.PresstheENDkeytoclearthe connection

______________________________________________________________________________________________________________

RESETALLZONEDNETWORKRECEIVERSTOMAXIMUMSIGNALSTRENGTH:

1.PresstheTALKkeyandenter81
2.Waitforthe“Ready”promptintheearpiece
3.Enterthecode1070followedbythekey
4.Amessagewillannounce“radiodeviceattenuationvaluesdisable…pleasewait”
5.Waitforthe“Ready”promptin
theearpiece
6.PresstheENDkeytoclearthe connection

______________________________________________________________________________________________________________
















Zonednetworkreceiversignalstrengthfunctionscanonlybeperformedfor60secondsfollowingasystemreset.
ThisfacilityisintendedforEngineersuseonly.


RP0096
