Enviro Q1LI User Manual

Initial Installation
QUALIFIED INSTALLERS ONLY
insuLating mateRiaL:
Depending on the chosen vent conguration, either one or both pieces of insulating material supplied with the
unit are required for correct installation.
Rear Vent: When using the rear vent conguration both the ceramic board and berglass insulation are required.
Place the ceramic board on top of the unit rst and then place the insulation on top of the ceramic board as
shown in Figure 25.
Top Vent: When using the top vent conguration only the gerglass insulation is required. Cut a notch in the
insulation, to t around the vent collar, and place on top of the unit as shown in Figure 26.
Fiberglass
Insulation
Ceramic
Board
Figure 25. Unit Insulation - Rear Vent
Figure 26. Unit Insulation - Top Vent
Fiberglass
Insulation
(cut around
vent collar)
21
