Enviro Q1LI User Manual

aiR shutteR:
The air shutter adjustment lever is on the right hand side of the venturi box (see Figure 4).
The air shutter allows the amount of air coming into the replace to be adjusted in order to accommodate
different climates and venting arrangements. Start the pilot and then the burner. Make sure the pilot
ame is burning normally and none of the burner ports are plugged. Let the replace burn for roughly
fteen minutes and then examine the ames, compare the ames to Figure 40.
The ideal ame will be blue at the base and light orange above. The ames should be of medium
height. If the ames look like this, no venturi adjustment is needed. If the ames are fairly short and
mostly blue, the replace is getting too
much air. Therefore, the air shutter
should be closed (pulled out) slightly
until the correct ames are achieved.
Flames that are very orange, with tall,
dark, stringy tips, are not getting enough
air. Open (push in) the venturi until the
ames clean up. If the venturi is opened,
or closed all the way, and the correct
ames cannot be attained, turn off the
gas and contact the dealer.
Warning: Incorrect venturi adjustment
may lead to improper combustion, which
is a safety hazard. Contact the dealer if
there is any concern about the venturi
adjustment.
Figure 4. Air shutter adjustment lever.
8
Operating Instructions
Less Air
More Air
Air Shutter Adjustment
noRmaL sounDs DuRing opeRation:
Table 1: Normal Sounds
Component Sound & Reason
Q1LI & Surround Panels Creaking when heating up or cooling down.
Burner Light pop or poof when turned off; this is more common with LP units.
Temperature Sensor Clinking when it senses to turn the blower on or off.
Pilot Flame Quiet whisper while the pilot ame in on.
Blower / Fan Air movement that increase and decreases with the speed of the blower. The
blower is pushing the heat from the replace into the room.
Gas Control Valve Dull click when turning on or off, this is the valve opening and closing.
Remote contRoL opeRations:
The Proame 2 GTMFL is a modular remote control system that directs the functions of the Q1LI.
The Proame 2 GTMFL is congured to control the on/off main burner operation, its ame levels and
provides on/off and Smart thermostatic control of the appliance. The system controls a remotely actuated
120V/60Hz power outlet, and fan speed through six (6) levels.
