Enviro Q1LI - Initial Installation; Corner Installation:

Initial Installation
QUALIFIED INSTALLERS ONLY
coRneR instaLLation:
The dimensions for installing a replace in the corner of a room are given in Figures 29 and 30. Refer to “InItIal
InstallatIon - allowaBle co-axIal Vent confIguratIons” for allowable pipe lengths.
Do not interfere with the structural integrity of the walls.
15
3
4
"
(260mm)
25
1
4
" (641mm)
27
7
8
"
(562mm)
13
3
4
"
(203mm)
55
7
8
" (1123mm)
39
1
2
"
(794mm)
Outside Wall
Inside Wall
Figure 29. Dimensions for a corner installation, rear
vented.
Figure 30. Dimensions for a corner installation, top
vented.
15
3
4
"
(260mm)
25
1
4
" (641mm)
39
1
2
"
(1003mm)
27
7
8
"
(709mm)
55
7
8
" (1123mm)
13
3
4
" (203mm)
Outside Wall
Inside Wall
23
