Initial Installation
QUALIFIED INSTALLERS ONLY
co-LineaR venting aDapteR Kit (50-2982):
The Q1LI can be converted from solid co-axial venting to 3” (76mm) exible co-linear venting to allow
for installation into exisiting masonary replaces (see Figures 37-39). Co-linear venting can not be used
in combustible chimney installations. This adapter kit is for vertical terminations only and can’t be
connected to a chimney ue serving a seperate solid-fuel burning stove or appliance.
WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts
specically approved with this appliance may result in property damage or personal injury.
Adapter Kit Contents:
Vent Plate Adapter
Vent Plate Adapter
Ceramic Gasket
Exhaust Spigot
Ceramic Flange
Gasket
3” Dia. Exhaust
Spigot
Exhaust Spigot
Ceramic Tube
Gasket
Figure 37: Co-Linear Venting Kit Contents
31
