Epec 5050 Technical Document

Technical Manual 5050 / MAN000539 Page 13/92
Epec Oy reserves all rights for improvements without prior notice
Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet
Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi
FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland
X1.17
CAN1L
X1.18
CAN1L
X1.19
CAN1L TERMINATOR
X1.20
AI/DI_Type011
2,2 kΩ +10 V / 220 Ω GND
/ 47,5 kΩ GND
0..22 mA 0..10 V
X1.21
AI/DI_Type011
2,2 kΩ +10 V / 220 Ω GND
/ 47,5 kΩ GND
0..22 mA 0..10 V
X1.22
PWM/DO/DI_Type005
2,2 kΩ +10 V / 12,4 kΩ GND
P1 / B Nominal current 4 A
X1.23
PWM/DO/DI/CM_Type007
12,4 kΩ GND
P1 / N Nominal current 2,5 A
X1.24
Logic Power Supply
X1.25
ETHERNET TD+
X1.26
ETHERNET TD-
X1.27
ETHERNET RD+
X1.28
ETHERNET RD-
X1.29
PWM/DO/DI_Type006 2,2 kΩ +10 V / 12,4 kΩ GND P1 / C Nominal current 2,5 A
X1.30
PWM/DO/DI_Type006 2,2 kΩ +10 V / 12,4 kΩ GND P1 / C Nominal current 2,5 A
X1.31
PWM/DO/DI_Type006 2,2 kΩ +10 V / 12,4 kΩ GND P1 / D Nominal current 2,5 A
X1.32
PWM/DO/DI_Type006 2,2 kΩ +10 V / 12,4 kΩ GND P1 / D Nominal current 2,5 A
X1.33
PWM/DO/DI_Type005 2,2 kΩ +10 V / 12,4 kΩ GND P1 / E Nominal current 4 A
X1.34
PWM/DO/DI_Type005 2,2 kΩ +10 V / 12,4 kΩ GND P1 / E Nominal current 4 A
X1.35
PWM/DO/DI_Type005 2,2 kΩ +10 V / 12,4 kΩ GND P1 / B Nominal current 4 A
X2.1
Power1 GND
X2.2
Power1 GND
X2.3
GND
X2.4
REF +10V_Type004 +10 V 250 mA
X2.5
REF +5V_Type015 +5 V 350 mA
X2.6
DI/PI_Type001 2,2 kΩ +10 V / 12,4 kΩ GND f Thresh. 5 /10 V
X2.7
DI/PI_Type001 2,2 kΩ +10 V / 12,4 kΩ GND f Thresh. 5 /10 V
X2.8
DI/PI_Type001 2,2 kΩ +10 V / 12,4 kΩ GND g Thresh. 5 /10 V
X2.9
DI/PI_Type001 2,2 kΩ +10 V / 12,4 kΩ GND g Thresh. 5 /10 V
X2.10
GND
X2.11
GND
X2.12
GND
X2.13
PWM/DO/DI/CM_Type007 12,4 kΩ GND P1 / Q Nominal current 2,5 A
X2.14
PWM/DO/DI/CM_Type007 12,4 kΩ GND P1 / Q Nominal current 2,5 A
X2.15
DI/PI_Type002 12,4 kΩ GND
X2.16
DI/PI_Type003 2,2 kΩ +10 V / 12,4 kΩ GND h
X2.17
DI/PI_Type003 2,2 kΩ +10 V / 12,4 kΩ GND h
X2.18
DI/PI_Type002 12,4 kΩ GND
X2.19
DI/PI_Type003 2,2 kΩ +10 V / 12,4 kΩ GND i
X2.20
DI/PI_Type003 2,2 kΩ +10 V / 12,4 kΩ GND i
X2.21
Reserved For factory use only 0/4..20 mA
X2.22
Reserved For factory use only 0/4..20 mA
