Conducted disturbance at main ports emission test
• Test method EN 55022, CISPR 16-2-1
Frequency
(MHz)
Limit value (dBmV)
0,15 - 30
66/56/60 (QP)
0,15 – 30
56/46/50 (AVE)
EN 61000-6-2 (2005)
Electromagnetic compatibility-generic immunity standard
part6-2: industrial environment
Conducted radio-frequency common mode
immunity test
• Test method EN 61000-4-6
• Performance criterion A
Specification Port Test
level
Frequency
range 0,150-
80
MHz
Modulation
AM80% 1 kHz
Sweep step
1%, time/step
3s
DC
input
port
10 Vemf
Signal
ports
10 Vemf
Radiated radio-frequency electromagnetic field
immunity test
• Test method EN 61000-4-3
• Performance criterion A
Specification
Range
(MHz)
Test
level
Frequency range
80-2700 MHz
Modulation
AM 80% 1 kHz
Sweep step 1%,
time/step 3 s
80-2500
10 V/m
2500-
2700
3 V/m
Electrical fast transient (EFT/B) immunity test
• Test method EN 61000-4-4
• Performance criterion B
Test pulse
Port
Test level
5 (Tr) / 50 (Th)
ns, repetition
frequency 5 kHz,
duration 5
minute
DC input
port
± 2,0 kVp
Signal
port
± 1,0 kVp
