68
Operator's instructions
5. Operating
Hydraulic feed rotation
Safety
Operation
NOTE: Pay attention to how the hoses move during rotation in order to prevent them from
being trapped or damaged in some other way.
1. Position the feeder so that it is in such a position that the hydraulic feed rotation can rotate
freely without damaging the feeder or other parts, see figure.
2. Press and hold touch button (19) and, at the same time, move the left-hand multifunction
lever (1) to the left or right for the desired position, see illustration.
Risk of injury
Moving parts
Risk of personal injury
The feeder must be in horizontal position during
rotation.
Deactivate the remote control box during rotation in
order to avoid the risk of accidental
operation.
