8. Options
Auxiliary hydraulic fittings
Figure: Auxiliary hydraulic fittings
The auxiliary hydraulic fittings provide hydraulic power to the machine's auxiliary
applications (hydraulic sharpener, etc.)
1. Connect the equipment's output and return to the quick connectors (C).
2. Press button B from the control panel to power the auxiliary application.
3. To interrupt hydraulic power to the application, press button A.
Before disconnecting the auxiliary
application from the machine, make sure
the auxiliary system is not powered
(indicator light D off)
Protect your eyes from contact with
hydraulic oil.
Wear protective goggles.
