Eppendorf Reference 2 - Disassembling the single-channel pipette ≥ 2 mL

6.2 Disassembling the single-channel pipette ≥ 2 mL
Abb. 6-3: Single-chann el lower part ≥ 2 m L
Fig. 6-3: Single-channel lower part ≥ 2 mL
6.2.1 Removing the lower part
1Piston mount
2 Piston spring
3Piston guide
4Piston
5 Cylinder with tip cone
6 Filter sleeve with protection filter
1. Unscrew the ejector sleeve.
1 4
5
6
2 3
