 MMS6110Directionforuse
 Visualization  Page27



Start
Stop
Start
Stop
time
Runup
rundown
Sub
speed.
Nomin.
speed
+Tol.
Over
speed.
-Tol.

Eachrun-upresp.run-downconsistsofapprox.600measuringpoints.Foreachofthem
speed,amplitudesofbothchannelsandtimearestored.Inordertoachievecontinuoustime
distancesbetweenthemeasuringpoints,theprogramperformsatimeoptimizingfunction
withoutloosingamplitudepeaks(neitherinpositivenorinnegativedirection).
Astartedbutinterruptedrun-uporrun-downwillbediscarded,onlythelastcompleterunre-
mainsstored.

Bymeansofthecursor,individualmeasurementsmaybechosen.
Selection: ByclickingwiththemousecursororbystrikingtheTABkey,themeas-
urementpointscanbeselected.Havingdonethis,trianglemarkswillap-
pearattheendsoftheXandYaxis.
Moving: Drawthecursorbykeepingthemousekeypressedandclickingameas-
uringpointorbymovingthecursorwiththecursorkeys→←↑↓.
