14
Figure 2-2
Step3: Attach the propeller.
Step4: Attach the Φ12 washer.
Step5: Tighten the nut with 19mm
(3/4 inch) socket wrench.
Step6: Attach the Anode.
Step1: Attach the Φ16 washer.
Step8: Screw and tighten the nut
with M6 hexagon wrench.
Step2: Fix the pin to the hole of shaft.
Step7: Attach the Φ6 washer.
