5.3 Power Adjusting
5.3.1 Power Adjusting for Evo Control System
Please place the safety switch on the Evo control system before operation.
The Evo Control system is mainly used to adjust the input power of the motor. When
the battery is well connected and switched on, power on the control system to start
the outboard, then slowly push/rotate the throttle forward position to increase the
power. The maximum forward/backward power is shown below.
Figure 5-5
Figure 5-6
Model Max Forward Power Max Backward Power
NAVY 3.0 Evo 3 kW 3 kW
NAVY 6.0 Evo 6 kW 6 kW
Before power on the Control system, please reset the throttle to zero position.
If you nd a blinking “RESET” on the display panel, you are reminded to reset the
throttle to zero position.
If you pull the throttle from the forward position to the backward position direct-
ly, the motor will rst stop shortly, then start turning to the reverse direction.
Forward
Zero position
Backward
Evo Remote Control
Forward
Backward
Neutral
