EPSON Stylus COLOR 680/777/777i Revision B
Appendix
C
onnector Summary
1
30
NOTE:
*1 Adjusted at factory.
*2 Initialized after performed panel initialization of EEPROM.
*3 Initialized after performed panel initialization of the ink overflow.
3CH
Printer For CSIC
00H
8:R4C62
10
9:R4C64
90
3DH CSIC1_InkName1;
00H
3EH CSIC2_InkName1;
3FH
Head Actuator Rank
ID for VhN
+1<=n<=+32
00H (*1)
40H
Head Actuator Rank
ID for VhM
+1<=n<=+37 00H
00H (*1)
41H
Head Actuator Rank
ID for VhL
+1<=n<=+34 00H
00H (*1)
42H
Head Actuator Rank
ID for VhU
+1<=n<=+40 00H
00H (*1)
43H
Head Actuator Rank
ID for VhM2
+1<=n<=+34 00H
00H (*1)
44H
Head Actuator Rank
ID for VhB
+1<=n<=+34 00H
00H (*1)
45H
Head Actuator Rank
ID for AR
0<=n<=+6 00H
00H (*1)
46H
Head Actuator Rank
ID for IwB
+30<=n<=+70 00H
00H (*1)
47H
Head Actuator Rank
ID for IwC
+30<=n<=+70 00H
00H (*1)
48H
Head Actuator Rank
ID for IwM
+30<=n<=+70 00H
00H (*1)
49H
Head Actuator Rank
ID for IwY
+30<=n<=+70 00H
00H (*1)
4AH
Head Actuator Rank
ID for IwLC
+30<=n<=+70 00H
00H (*1)
Address Explanation Setting
QPIT
setting
Factory
setting
4BH
Head Actuator Rank
ID for IwLM
+30<=n<=+70 00H
00H (*1)
4CH
|
5DH
USB ID 00H
|
00H
(*1)
|
(*1)
5EH
Market ID 0:EURO/ASIA:Stylus COLOR 680
1:EAI:Stylus COLOR 777
2:Custom
00H
EURO/
A
SIA:00H
EAI:01
H
5FH Reserved
60H
|
7DH
Model Name 00H
|
00H
-
|
-
7EH Password 55H 55H
7FH Password 33H 33H
Address Explanation Setting
QPIT
setting
Factory
setting
