Epson 680Pro - LQ B/W Dot-matrix Printer - 5.1.11 Protection Counter Check;Reset

EPSON Stylus COLOR 680/777/777i Revision B
Adjustment
O
verview
1
12
5.1.11 Protection Counter Check/Reset
The program allows you to check or clear the current protection counter value. (waste
ink amount counter)
You can confirm or clear the current protection value by main unit alone. Refer to
Section 1.4.3.)
NOTE: You can confirm or clear the current protection value by main unit alone.
Refer to section 1.4.3
[Check the present counter value]
1. Choose the “Check the present counter” in the “Maintenance “menu and click the
“OK” button.
Figure 5-20. Choose the Check the present counter
B
2. By clicking the”OK” button, following menu is displayed.
Figure 5-21. Check the present counter
3. After read the Caution description on the above menu, click the “OK” button in the
menu. The present counter value is displayed on the bottom column as following
figure.
Figure 5-22. Present counter value
