Removing the Feed Roll Unit in the Standard 250-Sheet Tray
1. Pull the standard 250-sheet tray out of the printer about 200 mm. Hold the standard 250-sheet tray
with both hands, and remove it from the printer.
Note:
Ensure that you remove all the paper from the standard 250-sheet tray before removing the feed roll
unit.
2. Holding the feed roll tabs with your fingers, pull the feed roll unit out of the groove in the axle.
Epson AcuLaser C2900 Series User’s Guide
Maintenance 220
