Epson DFX-9000 Repair Guide

Epson DFX-9000 Field Repair Guide 3/29/07
Control Panel Map Printer Component, Software Item, LCD Display, Printer Button Page 5.
Default Settings Mode and Options
Power-On Default Settings Mode
With the printer off hold the Font button down & then
power on the printer. If the LCD indicates:
SETTINGS MODE you have entered default settings
mode. Within the default settings mode you have three
menus to select from using the Tear off & Top of form
buttons. Once the desired menu has been selected use
the Font & Pitch buttons to scroll through the menu.
Once the desired setting to changed has been located
use the Tear off & Top of form buttons to change the
setting.
Powering off the unit will save the settings.
Default Settings Menu Options
1. Label base pos - Paper left edge, First dot.
2. Label top pos - 0/216 inches
to 4752/216 inches
3. Label length - 0/216 inches to 4752/216 inches
4. Label left pos - 0/120 inches to 1440/120 inches.
5. Label width - 0/120 inches
to1440/120 inches.
6. Base sheet PG - 0 to14.
7. Label paper PG - 0 to 14.
1. Pause - Unlock, lock.
2. Micro feed - Unlock, Lock.
3. Load - Unlock
, Lock.
4. LF - Unlock, Lock
.
5. FF - Unlock,Lock.
6. Top of Form - Unlock, Lock.
7. Tear Off - Unlock
, Lock.
8. Font - Unlock, Lock
.
9. Pitch - Unlock, Lock.
10. Front/Rear - Unlock, Lock
.
11. Menu - Unlock, Lock.
12. Reset - Unlock, Lock.
1. Print settings
Panel lock out
Print settings
Forms w/labels

Epson DFX-9000 Specifications

General

Color	No
Built-in barcodes	Code 39, POSTNET, UPC-A, UPC-E
Maximum resolution	240 x 144 DPI
Maximum print size	A4 (210 x 297 mm)
Standard interfaces	Serial
Dimensions (WxDxH)	700 x 378 x 363 mm
Power requirements	100-240V, 50-60Hz
Connectivity technology	Wired
Compatible operating systems	Microsoft Windows 95 / 98 / 2000 / Me / XP/ Windows NT 4.0
Sound pressure level (printing)	58 dB
Mean time between failures (MTBF)	20000 h
Sustainability certificates	ENERGY STAR
Power consumption (standby)	1.85 W
Power consumption (typical)	7.5 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
