Epson EB-520 User Manual

Submenu Function
Tracking
(Only available when analog RGB computer signals are being
input.)
You can adjust computer images when vertical stripes appear in
the images.
Sync.
(Only available when analog RGB computer signals are being
input.)
You can adjust computer images when flickering, fuzziness, or
interference appear in the images.
Position
(This item cannot be set when the source is HDMI.)
You can adjust the display position up, down, left, and right when
a part of the image is missing so that the whole image is projected.
Progressive
Interlace g (i) signal is converted to Progressive g (p). (IP
conversion)
Off: Ideal for images with a large amount of movement.
Video: Ideal for general video images.
Film/Auto: This is ideal for movie films, computer graphics, and
animation.
Noise Reduction
(This item cannot be set when Image Processing is set to Fast.)
Smoothes out rough images converted using progressive. There
are two modes. Select your favorite setting. It is recommended
that this is set to Off when viewing image sources in which noise
is very low, such as for DVDs.
HDMI Video
Range
When the projector's HDMI port is connected to a DVD player,
set the projector's video range according to the DVD player's
video range setting. If you are worried about floating black spots
or washed out parts in the image, set to Expanded.
Input Signal
You can select the input signal from the Computer1 port or the
Computer2 port.
If set to Auto, the input signal is set automatically according to
the connected equipment.
If colors do not appear correctly when set to Auto, select the
appropriate signal according to the connected equipment.
Submenu Function
Video Signal
You can select the input signal from the S-Video port or the
Video port. If set to Auto, video signals are recognized
automatically. If interference appears in the image or a problem
occurs such as no image is being projected when set to Auto,
select the appropriate signal according to the connected
equipment.
Aspect
You can set the
aspect ratio
g
for projected images.
s "Changing the Aspect Ratio of the Projected Image" p.55
Overscan
(This setting can only be adjusted when a component video
signal is being input.)
Changes the output image ratio (the range of the projected
image). You can set the cropping range to Off, 4%, or 8%. You
can select Auto when the source is HDMI. If you set to Auto, this
setting is changed automatically depending on the source.
Image Process-
ing
(This item cannot be selected if Easy Interactive Function is set
to PC Interactive)
When Fine is selected, priority is given to image quality, and the
image is projected.
When Fast is selected, priority is given to processing speed, and
the image is projected.
This improves the pen's tracking ability when using the
interactive features (EB-536Wi only).
Reset
You can reset all adjustment values on the Signal menu to their
default settings, except for Input Signal and Image Processing.
See the following to return all menu items to their default
settings.
s "Reset Menu" p.135
List of Functions
118

Epson EB-520 Specifications

General

Matrix size	0.55 \
Matrix type	3-panel (p-Si TFT active)
Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	0.5 - 1.3 m
Vertical scan range	50 - 85 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	50 - 108 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	15 °
Projector brightness (economic mode)	1600 ANSI lumens
Focus	Manual
Throw ratio	0.55:1
Focal length range	0 - 6.4 mm
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Full HD	No
Video processing	10 bit
Analog signal format system	-
Microphone in	Yes
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	0
Noise level	35 dB
Country of origin	China
Noise level (economic mode)	28 dB
RMS rated power	16 W
Placement	Desktop, Ceiling
Product type	Short throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.28 W
Power consumption (typical)	278 W
Power consumption (PowerSave)	219 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet width	800 mm
Pallet height	2250 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	40 pc(s)
Quantity per pallet (UK)	60 pc(s)
Quantity per pallet layer	4 pc(s)
Quantity per pallet layer (UK)	6 pc(s)

Weight and Dimensions

Depth	315 mm
Width	344 mm
Height	94 mm
Weight	3700 g
Package depth	490 mm
Package width	385 mm
Package height	210 mm
Package weight	5860 g
