screen, projection starts again from the beginning when it reaches
the end.
s "Image File Display Settings and Slideshow Operation Settings"
p.89
You can proceed to the next screen, return to the previous screen, or
stop playback while projecting a Slideshow.
a
If Screen Switching Time on the Option screen is set to No, files do
not change automatically when you select Play Slideshow. Press the
[
] button, the [Enter] button, or the [
]
] button to continue to the
next file.
You can use the following functions when projecting an image file with PC
Free.
Freeze
s "Freezing the Image (Freeze)" p.91
A/V Mute
s "Hiding the Image and Sound Temporarily (A/V Mute)" p.90
E-Zoom
s "Enlarging Part of the Image (E-Zoom)" p.92
Image File Display Settings and Slideshow Operation Settings
You can set the file display order and Slideshow operations on the Option
screen.
a
Select Option at the bottom of the file list screen, and then press
the [Enter] button.
b
When the following Option screen is displayed, set each of the
items.
Enable the settings by positioning the cursor on the target item and
pressing the [Enter] button.
The following table shows the details for each item.
Display Order
You can select to display the files in Name Order or Date
Order.
Sort Order
You can select to sort the files In Ascending or In
Descending order.
Continuous
Play
You can set whether to repeat the Slideshow.
Screen Switch-
ing Time
You can set the time for a single file to be displayed in Play
Slideshow. You can set a time between No (0) to 60
seconds. When you set No, auto play is disabled.
Effect
You can set the screen effects when changing slides.
Projection Functions
89

Table of Contents

Other manuals for Epson EB-520

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-520 and is the answer not in the manual?

Epson EB-520 Specifications

General IconGeneral
Matrix size0.55 \
Matrix type3-panel (p-Si TFT active)
Number of colors1.073 billion colors
Native aspect ratio4:3
Projection distance0.5 - 1.3 m
Vertical scan range50 - 85 Hz
Projection technology3LCD
Contrast ratio (typical)16000:1
Screen size compatibility50 - 108 \
Projector native resolutionXGA (1024x768)
Keystone correction, horizontal15 °
Projector brightness (economic mode)1600 ANSI lumens
FocusManual
Throw ratio0.55:1
Focal length range0 - 6.4 mm
Lamp power200 W
Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)10000 h
Full HDNo
Video processing10 bit
Analog signal format system-
Microphone inYes
USB connector typeUSB Type-A, USB Type-B
Serial interface typeRS-232
USB 2.0 ports quantity2
VGA (D-Sub) ports quantity3
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN (RJ-45) ports0
Noise level35 dB
Country of originChina
Noise level (economic mode)28 dB
RMS rated power16 W
PlacementDesktop, Ceiling
Product typeShort throw projector
Product colorWhite
Cable lock slot typeKensington
Power sourceAC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.28 W
Power consumption (typical)278 W
Power consumption (PowerSave)219 W
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Pallet width800 mm
Pallet height2250 mm
Pallet length1200 mm
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet40 pc(s)
Quantity per pallet (UK)60 pc(s)
Quantity per pallet layer4 pc(s)
Quantity per pallet layer (UK)6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth315 mm
Width344 mm
Height94 mm
Weight3700 g
Package depth490 mm
Package width385 mm
Package height210 mm
Package weight5860 g
