PC Interactive
Set when you want to operate a computer from the projected screen.
Submenu Function
Pen Operation
Mode
Set the operation mode and the number of users for the
interactive pen.
Two Users/Mouse (default)/One User/Mouse: Allows you to
perform mouse operations using the interactive pen.
One User/Pen: The pen input and Ink features are available in
Windows 8.1, Windows 8, Windows 7, and Windows Vista.
Enable Right
Click
(Only available when Pen Operation Mode is set to Two
Users/Mouse or One User/Mouse.)
When this is set to On, a long press of the pen tip acts as a right
click.
Advanced
 Pen Tip Button: Allows you to set operations for the pen tip of
the interactive pen. The default setting is Left Click.
 Auto Adjust Pen Area: When this is set to On (default), the
pen area is automatically adjusted as the resolution for the
connected computer changes. Set to Off if you do not want to
automatically adjust the pen area that has been manually
adjusted.
 Manual Adj. Pen Area: Adjusts the pen area manually.
Network Menu
When Network Protection is set to On in Password Protection, a message
is displayed and the network settings cannot be changed. Set Network
Protection to Off and then configure the network.
s "Setting Password Protection" p.98
Submenu Function
Wireless Mode
Set to Wireless LAN On when connecting the projector to
the computer over wireless LAN.
If you do not want to connect via wireless LAN, turn it Off
to prevent unauthorized access by others. The default value
is Wireless LAN On.
Net. Info. - Wire-
less LAN
Displays the following network setting status information.
 Connection Mode
 Wireless LAN Sys.
 Antenna Level
 Projector Name
 SSID
 DHCP
 IP Address
 Subnet Mask
 Gateway Address
 MAC Address
 Region Code
*
List of Functions
124

Epson EB-520 Specifications

General

Matrix size	0.55 \
Matrix type	3-panel (p-Si TFT active)
Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	0.5 - 1.3 m
Vertical scan range	50 - 85 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	50 - 108 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	15 °
Projector brightness (economic mode)	1600 ANSI lumens
Focus	Manual
Throw ratio	0.55:1
Focal length range	0 - 6.4 mm
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Full HD	No
Video processing	10 bit
Analog signal format system	-
Microphone in	Yes
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	0
Noise level	35 dB
Country of origin	China
Noise level (economic mode)	28 dB
RMS rated power	16 W
Placement	Desktop, Ceiling
Product type	Short throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.28 W
Power consumption (typical)	278 W
Power consumption (PowerSave)	219 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet width	800 mm
Pallet height	2250 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	40 pc(s)
Quantity per pallet (UK)	60 pc(s)
Quantity per pallet layer	4 pc(s)
Quantity per pallet layer (UK)	6 pc(s)

Weight and Dimensions

Depth	315 mm
Width	344 mm
Height	94 mm
Weight	3700 g
Package depth	490 mm
Package width	385 mm
Package height	210 mm
Package weight	5860 g
