Once the Configuration menu content has been set for one projector, you
can use it to perform batch setup for multiple projectors (batch setup
function). The batch setup function is only for projectors with the same
model number.
Use one of the following methods.
 Setup using a USB memory.
 Setup by connecting the computer and projector with a USB cable.
 Setup using EasyMP Network Updater.
This guide explains the USB storage device and the USB cable methods.
a
The following content is not reflected by the batch setup function.
 Network menu settings (except for Mail and Others menu)
 Lamp Hours and Status from the Info menu
 Perform batch setup before adjusting the projected image.
Adjustment values for the projected image, such as Keystone, are
also reflected by the batch setup function. If batch setup is
performed after adjusting the projected image, the adjustments you
made may change.
 By using the batch setup function, the registered User's Logo is set
for the other projectors. Do not register confidential information and
so on as the User's Logo.
Caution
Performing batch setup is the customers responsibility. If batch setup fails due
to a power failure, communication error, and so on, the customer is responsible
for any repair costs incurred.
Setting Up Using a USB Memory
This section explains how to perform batch setup using a USB storage
device.
a
 Use a FAT format USB storage device.
 The batch setup function cannot be used by USB storage device that
incorporate security functions. Use a USB storage device that does
not incorporate security functions.
 The batch setup function cannot be used by USB card readers or
USB hard disks.
Saving Settings to a USB Memory
a
Disconnect the power cord from the projector, and check that all
of the projector's indicators have turned off.
b
Connect the USB storage device to the projector's USB-A port.
a
 Connect the USB storage device to the projector. If the USB
storage device is connected to the projector through a USB
hub, the settings may not be saved correctly.
 Connect an empty USB storage device. If the USB storage
device contains data other than the batch setup file, the
settings may not be saved correctly.
 If you have saved a batch setup file from another projector to
the USB storage device, delete the file or change the file
name. The batch setup function cannot overwrite a batch
setup file.
 The file name for the batch setup file is PJCONFDATA.bin. If
you need to change the file name, add text after
PJCONFDATA. If you change to another file name, the
projector may not recognize it correctly.
 You can only use single-byte haracters for the file name.
Performing Batch Setup for Multiple Projectors
136

Epson EB-520 Specifications

General

Matrix size	0.55 \
Matrix type	3-panel (p-Si TFT active)
Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	0.5 - 1.3 m
Vertical scan range	50 - 85 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	50 - 108 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	15 °
Projector brightness (economic mode)	1600 ANSI lumens
Focus	Manual
Throw ratio	0.55:1
Focal length range	0 - 6.4 mm
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Full HD	No
Video processing	10 bit
Analog signal format system	-
Microphone in	Yes
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	0
Noise level	35 dB
Country of origin	China
Noise level (economic mode)	28 dB
RMS rated power	16 W
Placement	Desktop, Ceiling
Product type	Short throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.28 W
Power consumption (typical)	278 W
Power consumption (PowerSave)	219 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet width	800 mm
Pallet height	2250 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	40 pc(s)
Quantity per pallet (UK)	60 pc(s)
Quantity per pallet layer	4 pc(s)
Quantity per pallet layer (UK)	6 pc(s)

Weight and Dimensions

Depth	315 mm
Width	344 mm
Height	94 mm
Weight	3700 g
Package depth	490 mm
Package width	385 mm
Package height	210 mm
Package weight	5860 g
