Check Remedy
Is the
Aspect Ratio
g
set correctly? You can change the Aspect Ratio of the projected image to suit the type, the ratio of height and width, and the resolution
of the input signals.
s "Changing the Aspect Ratio of the Projected Image" p.55
Has condensation formed on the lens? If the projector is suddenly taken from a cold environment to a warm environment, or if sudden ambient temperature
changes occur, condensation may form on the surface of the lens, and this may cause the images to appear fuzzy. Set the
projector up in the room about one hour before it is used. If condensation forms on the lens, turn the projector off and
wait for the condensation to disappear.
Interference or Distortion Appear in Images
Check Remedy
Is the image signal format setting correct?
(Only when projecting images from a video source)
Change the setting according to the signal for the connected equipment.
s Signal - Video Signal p.117
Are the cables connected correctly? Check that all the cables required for projection are securely connected.
s "Connecting Equipment" p.26
Is an extension cable being used? If an extension cable is used, electrical interference may affect the signals. Use the cables supplied with the projector to
check if the cables you are using may be causing the problem.
Is the correct resolution selected?
(Only when projecting computer images)
Set the computer so that the signals being output are compatible with the projector.
s "Supported Monitor Displays" p.176
s
Computer's documentation
Are the
Sync.
g
and Tracking
g
settings adjusted correctly?
(Only when projecting computer images)
Press the [Auto] button on the remote control or the [Enter] button on the control panel to perform automatic
adjustment. If the images are not adjusted correctly even after performing automatic adjustment, you can also make
adjustments from the Configuration menu.
s Signal - Tracking, Sync. p.117
Is Transfer layered window selected?
(Only when projecting USB Display)
Click All Programs - EPSON Projector - Epson USB Display - Epson USB Display Ver.x.xx Settings, and then clear
the Transfer layered window checkbox.
Problem Solving
151
