b
Press the [ ], [ ], [ ], and [ ] buttons to select the image file
you want to project.
c
Press the [Enter] button.
The image is displayed.
a
Press the [ ] or [ ] buttons to move to the next or previous
image file.
d
To finish projecting, perform one of the following operations.
Projecting an image: Press the [Esc] button.
Projecting a movie: Press the [Esc] button to display the message
screen, select Exit, and then press the [Enter] button.
When projection is finished, you are returned to the file list screen.
Projecting Image Files in a Folder in Sequence (Slideshow)
You can project the image files in a folder in sequence, one at a time. This
function is called Slideshow. Use the following procedure to run
Slideshow.
a
To change files automatically when you run PC Free, set Screen
Switching Time from Option to anything other than No. The default
setting is 3 seconds.
s "Image File Display Settings and Slideshow Operation Settings"
p.89
a
Start PC Free.
The file list screen is displayed.
s "Starting PC Free" p.86
b
Use the [ ], [ ], [ ], and [ ] buttons to position the cursor
on the folder you want to run the Slideshow, and then press
the [Enter] button.
c
Select Slideshow at the bottom of the file list screen, and then
press the [Enter] button.
Slideshow starts, and the image files in the folder are automatically
projected in sequence, one at a time.
When the last file is projected, the file list is displayed again
automatically. If you set Continuous Play to On in the Option
Projection Functions
88

Table of Contents

Other manuals for Epson EB-520

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-520 and is the answer not in the manual?

Epson EB-520 Specifications

General IconGeneral
Matrix size0.55 \
Matrix type3-panel (p-Si TFT active)
Number of colors1.073 billion colors
Native aspect ratio4:3
Projection distance0.5 - 1.3 m
Vertical scan range50 - 85 Hz
Projection technology3LCD
Contrast ratio (typical)16000:1
Screen size compatibility50 - 108 \
Projector native resolutionXGA (1024x768)
Keystone correction, horizontal15 °
Projector brightness (economic mode)1600 ANSI lumens
FocusManual
Throw ratio0.55:1
Focal length range0 - 6.4 mm
Lamp power200 W
Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)10000 h
Full HDNo
Video processing10 bit
Analog signal format system-
Microphone inYes
USB connector typeUSB Type-A, USB Type-B
Serial interface typeRS-232
USB 2.0 ports quantity2
VGA (D-Sub) ports quantity3
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN (RJ-45) ports0
Noise level35 dB
Country of originChina
Noise level (economic mode)28 dB
RMS rated power16 W
PlacementDesktop, Ceiling
Product typeShort throw projector
Product colorWhite
Cable lock slot typeKensington
Power sourceAC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.28 W
Power consumption (typical)278 W
Power consumption (PowerSave)219 W
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Pallet width800 mm
Pallet height2250 mm
Pallet length1200 mm
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet40 pc(s)
Quantity per pallet (UK)60 pc(s)
Quantity per pallet layer4 pc(s)
Quantity per pallet layer (UK)6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth315 mm
Width344 mm
Height94 mm
Weight3700 g
Package depth490 mm
Package width385 mm
Package height210 mm
Package weight5860 g
