Epson EB-520 User Manual

Name Function
I
Audio Out port
Outputs audio from the currently projected image to an
external speaker.
J
Audio2 port
Inputs audio from equipment connected to the
Computer2 port.
K
SYNC IN/OUT port
(EB-536Wi only)
When installing multiple projectors in the same room and
using the interactive function, connect projectors using
the optional Remote control cable set (ELPKC28). Easy
Interactive Pen operations are stabilized when connected.
s "Connecting Multiple Projectors (EB-536Wi only)"
p.38
L
Speaker
Outputs audio.
M
HDMI port
Inputs video signals from HDMI compatible video
equipment and computers. This projector is compatible
with
HDCP g .
s "Connecting Image Sources" p.28
N
Computer2 port
Inputs image signals from a computer and component
video signals from other video sources.
O
Computer1 port
P
Remote receiver
Receives signals from the remote control.
Q
LAN port
Connects a LAN cable to connect to a network.
R
USB-B port
 Connects the projector to a computer using a USB cable,
and projects the images on the computer.
s
"Projecting with USB Display" p.45
 Connects the projector to a computer using a USB cable
to use the Wireless Mouse function.
s "Using the Remote Control to Operate the
Mouse Pointer (Wireless Mouse)" p.93
 When operating the mouse using the Easy Interactive
Pen, connect to the computer with the supplied USB
cable (EB-536Wi only).
s "Controlling a Computer from the Projected
Screen (Computer Interactive Mode)" p.62
Name Function
S
USB-A port
 Connects a USB storage device or a digital camera, and
projects images using PC Free.
s
"Projecting Images Stored on a USB Storage
Device (PC Free)" p.85
 Connects the optional Document Camera.
 Connects the optional Wireless LAN unit.
s "Installing the Optional Wireless LAN Unit"
p.36
 Connects the optional Quick Wireless Connection USB
Key.
s
"Installing the Optional Quick Wireless
Connection USB Key" p.37
T
Wireless LAN unit
fixing screw
This screw secures the wireless LAN unit cover.
Part Names and Functions
13

Epson EB-520 Specifications

General

Matrix size	0.55 \
Matrix type	3-panel (p-Si TFT active)
Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	0.5 - 1.3 m
Vertical scan range	50 - 85 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	50 - 108 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	15 °
Projector brightness (economic mode)	1600 ANSI lumens
Focus	Manual
Throw ratio	0.55:1
Focal length range	0 - 6.4 mm
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Full HD	No
Video processing	10 bit
Analog signal format system	-
Microphone in	Yes
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	0
Noise level	35 dB
Country of origin	China
Noise level (economic mode)	28 dB
RMS rated power	16 W
Placement	Desktop, Ceiling
Product type	Short throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.28 W
Power consumption (typical)	278 W
Power consumption (PowerSave)	219 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet width	800 mm
Pallet height	2250 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	40 pc(s)
Quantity per pallet (UK)	60 pc(s)
Quantity per pallet layer	4 pc(s)
Quantity per pallet layer (UK)	6 pc(s)

Weight and Dimensions

Depth	315 mm
Width	344 mm
Height	94 mm
Weight	3700 g
Package depth	490 mm
Package width	385 mm
Package height	210 mm
Package weight	5860 g
