You can use Screen Fit to correct the projected image under the following
conditions.
Screen size: less than or equal to 100"
Distance between projector and screen: approx. 1.2 to 3.0 m
Correction angle: approx. 20˚ right and left/approx. 30˚ up and down
1.2~3.0m
a
The projected image cannot be adjusted correctly if this range is
exceeded. Correct the projected image manually.
Screen Fit is unavailable when the projector is suspended from a
ceiling. Correct the projected image manually.
a
Press the [Screen Fit] button on the remote control or the control
panel during projection.
Using the remote control Using the control panel
b
Adjust the zoom ring so that the yellow frame is bigger than the
screen frame as shown below. Position the black message box in
the center of the screen.
If the yellow frame is still within the screen frame even after
adjusting the zoom ring to its maximum size, try moving the
projector further away from the screen.
c
Press the [Screen Fit] button or the [ ] button.
After the adjustment screen appears, the projected image is corrected
according to the
aspect ratio
g
of the image being input.
Adjusting Projected Images
39
