Epson G3 Series User Manual

Maintenance 9. Replacing Arm #1
G3 Rev.14 145
Name
Quantity
Notes
Maintenance
parts
Table Top
Mounting
Standard arm
250 mm
1
Arm #1_25ST
R12B031914
300 mm
1
Arm #1_30ST
R12B031915
350 mm
1
Arm #1_35ST
R12B031916
Curved arm
300 mm
1
Arm #1_30B
R12B031917
350 mm
1
Arm #1_35B
R12B031918
Multiple
Mounting
Standard arm
300 mm
1
Arm #1_M_30ST
R12B031919
350 mm
1
Arm #1_M_35ST
R12B031920
Curved arm
350 mm
1
Arm #1_M_35B
R12B031921
Tools
Hexagonal wrench
(width across flats: 2.5 mm)
1 For screw M3
Torque wrench
1
Flathead screwdriver
1
When changes the arm length, it requires the other cable unit for the new arm length.
Right / Left-curved arm have the shared maintenance parts.
CAUTION
■
Replacing Arm #1 should be done by two persons.
There are
dangers of main parts to fall or get damage.
