Epson PP 803 - Cut Sheet Tray (Only Printer PP 803; PP 806 ); Installing the Cut Sheet Tray

Options
7-13
7.4
Cut Sheet Tray
(only for printer
PP 803
or
PP 806
)
Use the cut sheet tray (1) to collect a batch of paper sheets or formsets in the
output area.
7.4.1
Installing the Cut Sheet Tray
$
Remove the manual sheet feeder (6).
$
Remove the
upper tractor cassette
.
$
Insert the cut sheet tray (1) in position of the
upper tractor cassette
.
$
Lift the lower part (2) of the cut sheet tray and align it to the length of the
paper in use.
$
To get a correct collection of the sheets or forms loosen screw (3) and
swivel the part (4) down for heavy paper (> 80 g/m²) or up for light
paper (< 80 g/m²).
Note:
Make a test print and repeat the procedure if necessary.
$
Mount the ASF cassettes (see paragraph
7.2.3 Installing the ASF
Cassettes
).
