Getting Started

1-13

1.8.2

Fanfold Paper Feeding

Note:

Ensure that all transport locks are removed.

The printer has to be placed at the front edge of the table or on the printer

stand as described in chapter

7.1 Printer Stand

Remove the manual sheet feeder (1) of printer

PP 806

(option for printer

PP 803

, see also paragraph

7.5 Manual Sheet Feeder

Insert the lower (2) or the upper (3) tractor cassette, or both.

Note:

The second Tractor Cassette is for printer

PP 803

an option.
