Maintenance
5-5
5.3
User Replaceable Parts
The life time of the print head is specified being 600 Mio. strokes per
needle.
5.3.1
Print Head Exchange
Note:
The print head may be very hot immediately after printing.
$
Power the printer ON:
$
Release the rear cover (2) by pressing simultaneously the two
lockingbuttons (1) and swivel the rear cover backwards.
$
Press
until
UNLOCK PRINTHEAD
is displayed.
Now the print head is unlocked.
1
Locking Buttons
2
Rear Cover
3
Ribbon Cassette
4
Print Head (in park position)
$
Slide out the Ribbon cassette (3) to the rear.
$
Power the printer OFF.
