Table 6: (Cont.) Graphics Modes
Escape Sequence Function
ESC * P1 P2 P3 v1 . . . vn Select Various Graphics Modes
P2 + P3 * 256 = number of columns
(0/0...F/F)
v1 .. vn = binary data in hex code
(0/0...F/F)
Parameter Table Graphic Density:
P1 Graphic type dots / max. number hor. density
column of columns ( dpi )
0/0 Standard Density (K) 8 816 60
0/1 Double Density (L) 8 1632 120
0/2 2xDensity / 2xSpeed (Y) 8 1632 120 *)
0/3 Quadruple Density (Z) 8 3264 240 *)
0/4 CRT I 8 1088 80
0/6 CRT II 8 1224 90
2/0 Standard Density 24 816 60
2/1 Double Density 24 1632 120
2/6 CRT III 24 1224 90
2/7 Triple Density 24 2448 180
2/8 Hex Density 24 4896 360 *)
*) consecutive horizontal dots cannot be printed.
Example:
box 8x8 dots with center point 2x2 dots, standard density, 8 dots /
column
hex: 1B 2A 00 08 00 FF 81 81 99 99 81 81 FF
