18.2 Software Reset
Figure 40 Example Flow(Software Reset)
Start
1) Power ON
3) Dummy Read
4) Write 00h Address 1Eh
5) Write 80h Address 1Eh
6) Write 6Ch Address 50h
7) Write 01h Address 53h
8) Write 03h Address 66h
9) Write 02h Address 6Bh
10) Write 01h Address 6Bh
12) Wait 125 ms
2) Wait > 30 ms
Software Reset complete
Next process
Initialization same as Power-On Reset is performed by this
processing.
As for the register value after software reset,
See 13.2.2. Register initial value.
Notes.
It has possibility leak current occurs from step 6) to step 10).
because all power switch are turned to ON while this.
After step 5), please complete the process immediately.
3) In a dummy lead, ignore NACK/ACK from RTC.
10) TEST bit is cleared automatically in step10.
Both time and a calendar register are not initialized in any values
by this Software Reset.
Both a calendar and Time before reset are maintained.
/RST signal outputs Low 95ms Max from step10.
Please care /RST active signal.
And a VLF bit is set to 1.
Please clear VLF to 0.
