Epson Stylus C62 User Manual

EPSON Stylus C50/C60/C61/C62 Revision C
Appendix Connector Summary 149
data in 00h ~ 2Fh are written to EEPROM at NMI
*a : D4 mode setting (EEPROM 2EH)
USB Parallel
24H
|
27H
Ink counter Clc 00H
|
00H
00H
|
00H
28H Memory of PF phase
position
00H -
29H Reserved 00H 00H
2AH Reserved 00H 00H
2BH Reserved 00H 00H
2CH Reserved 00H 00H
2DH Reserved 00H 00H
2EH D4 mode I/F Bit7:Reserved 05H 05H
*a
Bit6:Reserved
Bit5:Reserved
Bit4:Reserved
Bit3:D4 mode USB
Bit2:
Bit2:D4 mode USB
Bit1:
Table 7-17. EEPROM address map (Stylus C61/C62) (continued)
Address Explanation Setting
QPIT
setting
Factory
setting
2FH Interface setting Bit7:Interface selection
*b
Bit6:
00H 00H
Bit5:Interface Time-out
0:10 second
1:30 second
Bit4:ECP mode
0:Off
1:On
Bit3:IEEE1284 mode
0:On
1:Off
Bit2:Compatibility speed
0:Fast
1:Slow
Bit4:ECP speed
0:Fast
1:Slow
Bit0:Reserved
Bit3 Bit2 D4 mode Bit1 Bit0 D4 mode
00Auto 00Auto
0 1 On 0 1 On
10Off 10Off
Table 7-17. EEPROM address map (Stylus C61/C62) (continued)
Address Explanation Setting
QPIT
setting
Factory
setting

Epson Stylus C62 Specifications

Printing

printing method	4-color (CMYK) drop-on-demand Micro Piezo ink jet technology
resolution (dots per inch)	Up to 5760 x 720 optimized dpi
print speed (black text memo)	14 ppm

Paper Handling

maximum paper size	up to 8.5" x 44"
input paper tray capacity	100 sheets/10 envelopes
envelope types	No. 10, DL, C6

Dimensions and Weight

dimensions (L x W x H)	18.8" x 10.2" x 7.1"
weight	7.5 lb
maximum printable area	8.26" x 10.76"
