EPSON Stylus C50/C60/C61/C62 Revision C
Troubleshooting Unit Level Troubleshooting 72
Table 3-8. Paper out error condition and possible cause
Error condition
LED indication
STM3 message
Occurrence
timing
CR position at the
power on timing
Unit/Part name Possible cause Check table
Paper out error
Power : On
Error : On
Paper not loaded
correctly
Operation -
ASF unit
The Compression spring 2.50 comes off.
Refer to Table 3-9
The Tension spring 29.1 comes off.
Holder shaft unit
The Tension spring 0.143 comes off.
The Dowel in Clutch comes off.
The Clutch tooth is damaged.
The Clutch is damaged.
The friction of the LD roller is lowered.
The Paper return plate disturbs the rotation of the LD roller.
Paper guide upper/left The Paper guide upper (only HP side) comes off.
PF motor
The PF motor connector cable comes off.
The PF motor is defective.
The PF motor connector cable is damaged.
Pump unit
The Compression spring 1.764 comes off.
The tip of the Change lever is damaged.
Table 3-9. Check point for the paper out error according to each phenomenon
Occurrence
timing
CR position
Detailed phenomenon
Defective
unit/part name
Check point Remedy
Operation
-
The Hopper does not operate during the
paper loading sequence although the LD
roller rotates to load a paper from ASF
unit.
ASF unit
1. Check if the Hopper operates correctly in the paper
loading sequence.
1. Reassemble the Compression spring 2.50
between the ASF frame and the Hopper.
Comp. Spring 2.50

Epson Stylus C62 Specifications

Printing

printing method	4-color (CMYK) drop-on-demand Micro Piezo ink jet technology
resolution (dots per inch)	Up to 5760 x 720 optimized dpi
print speed (black text memo)	14 ppm

Paper Handling

maximum paper size	up to 8.5" x 44"
input paper tray capacity	100 sheets/10 envelopes
envelope types	No. 10, DL, C6

Dimensions and Weight

dimensions (L x W x H)	18.8" x 10.2" x 7.1"
weight	7.5 lb
maximum printable area	8.26" x 10.76"
