EPSON Stylus C50/C60/C61/C62 Revision C
Troubleshooting Unit Level Troubleshooting 71
Operation
-
When a top of a paper at the correct
timing during the paper loading
sequence, the paper is ejected
immediately without setting the paper
setting position for printing. But, in this
time, next paper is loaded to the PE
detection lever.
ASF unit
1. Check if the Paper return plate operates correctly in the
paper loading sequence.
1. Reassemble the Tension spring 29.1 between
the ASF frame and the Paper return plate.
The top of a paper does not go through
between the Paper eject roller and the
Star wheel.
Front frame **
1. Check if the Star wheel comes off.
2. Check if the Front frame is bent down.
3. Check if the Front frame is correctly assembled.
1. Reassemble the Star wheel correctly.
2. Replace the Front frame with new one.
3. Reassemble the Front frame correctly.
Paper eject roller
unit **
1. Check if the Paper eject roller shaft is correctly
assembled.
2. Check if the Spur gear 60 comes off.
1. Reassemble the Paper eject roller shaft to the
Lower housing correctly.
2. Replace the Printer mechanism with new one.
A paper is loaded from the ASF unit, and
it is fed correctly. But, the paper feeding
sequence is performed without loading a
paper from the next paper loading
sequence.
Holder shaft unit
1. Check if the Torsion spring 0.22 for the PE sensor lever
comes off.
1. Set the Torsion spring 0.22 for the PE sensor
lever to the suitable position.
The top of a paper is not loaded to the PF
roller.
Paper guide upper/
left **
1. Check if the Paper guide upper/left is correctly
assembled.
1. Reassemble the Paper guide upper/left to the
Main frame correctly.
* The CR unit can move to home position even if the Tension spring 0.22 comes off or the HP/PE sensor is not correctly placed. However, the HP detection lever keeps the high signal condition in
the next operation. Therefore, the paper jam error is detected.
** In case that the paper jam error occurs in each operation, the jammed paper contacts the nozzle surface of the Printhead and the Printhead may be damaged.
Table 3-7. Check point for the paper jam error according to each phenomenon
Occurrence
timing
CR position
Detailed phenomenon
Defective
unit/part name
Check point Remedy
Torsion spring 29.1
Spur gear 60

Epson Stylus C62 Specifications

Printing

printing method	4-color (CMYK) drop-on-demand Micro Piezo ink jet technology
resolution (dots per inch)	Up to 5760 x 720 optimized dpi
print speed (black text memo)	14 ppm

Paper Handling

maximum paper size	up to 8.5" x 44"
input paper tray capacity	100 sheets/10 envelopes
envelope types	No. 10, DL, C6

Dimensions and Weight

dimensions (L x W x H)	18.8" x 10.2" x 7.1"
weight	7.5 lb
maximum printable area	8.26" x 10.76"
