28
CODE128
• Specify a character string of 2 to 255 digits.
• Specify either a start code or code selection characters (CODE A, CODE B, or CODE C) for the
first two digits.
• Indicate special characters with a combination of ‘{’ followed immediately by a single character.
• Adding a check mark to Automatically Convert Symbol Overall Width to Minimum results
in the overall width of the Code 128 symbol being automatically converted to the minimum.
Use this function when it is not necessary to specify a code set and you want to print barcodes
by only inputting data for a desired symbol.
Manually specify the code set if not checked.
If code set C is specified, consider the two created digits as ASCII decimal numbers and specify
the corresponding ASCII character(s).
Example) “37”: Specify as “%”.
“65”: Specify as “A”.
“979899”: Specify as “abc”.
• An error occurs if the data immediately following ‘{’ is not as indicated below.
• Special HRI characters are expressed as follows.
Control characters ASCII Control characters ASCII Control characters ASCII
SHIFT {S CODE C {C FNC3 {3
CODE A {A FNC1 {1 FNC4 {4
CODE B {B FNC2 {2 '{' {{
Control characters HRI characters
SHIFT Not printed
CODE A/B/C Not printed
FNC1-4 Space is printed
Control characters (00h to 1Fh, and 7Fh) Space is printed
