1-22 General Information Rev. A
1.7 Other Specifications
1.7.1 Internal Buffer
1. Receive buffer selectable as 45 or 4 KB using the DIP switch.
2. User-defined buffer (both for user-defined characters and user-defined bit images)
Receipt: 12KB; Slip: 3KB
3. Macro buffer 2KB
4. NV (non-volatile) bit image buffer 384KB
5. NV (non-volatile) user memory 1KB
1.7.2 Electrical Characteristics
Supply voltage: +24 VDC
±
10% (optional power supply: EPSON PS-170)
Ripple voltage: 300 mVpp or less
(only when the printer is used with the MICR reader)
Current consumption (at
24V except for drawer
kickout driving)
Slip: Operating:
Mean: Approximately 1.7A
(Character font A α-N, all columns printing)
Peak: Approximately 5.5A
When the print platen is released: 2.0A (200 msec)
Receipt: Operating:
Mean: Approximately 1.8A
(Character font A α-N, all columns printing)
Peak: Approximately 7.7A
Standby:
Mean: Approximately 0.2A
