Rev. A Setup 3-3
TM-H6000II Technical Reference Guide
SLIP
❏ This light blinks when the printer is ready to receive slip paper. It stays on during printing
on slip paper and blinks again when slip paper should be removed. When the slip paper is
removed in the slip removal waiting state, the printer enters the paper roll mode two
seconds later. The SLIP LED light is on during this time. The blinking patterns for the slip
inserting and removal waiting states are different as follows:
3.1.2.2 Control Panel Buttons
The control panel has two paper buttons that you may have to use, although most paper
handling functions will be handled by your software.
FEED
Use this button to feed roll paper or to start a roll paper self test. (See the instructions later in this
chapter.)
RELEASE
Use this button to release slip paper or to start a slip paper self test. (See the instructions later in
this chapter.)
Panel Button Operations
ESC/POS command can be set to enable or disable the panel buttons, but in some situations the
setting of ESC/POS command is ignored, as you can see in the table below:
State
SLIP LED Blinking Pattern
Slip insertion waiting
Slip removal waiting
Check insertion waiting
(only for MICR-equipped model)
320 ms
2080 ms
1760 ms
