Epson TM-S1000 Technical Reference Guide

Chapter 1 Product Overview
11
1
Product Configuration
There are multi feed models and single feed models depending on the document feeding
methods.
For the multi feed models, a 30 dpm model, a 60 dpm model, and a 90 dpm model are available
depending on the document processing speeds. For the single feed models, a one pocket model
and a two pocket model are available depending on the number of pockets they have, into which
documents are ejected.
dpm: the number of docume
nts that can be processed in 1 minute (Documents Per Minute)
Interface
USB Hi-Speed/Full-Speed interface (USB 2.0 compliant)
Color
EDG (Epson Dark Gray)
Model name
Multi feed models Single feed models
30 dpm
model
60 dpm
model
90 dpm
model
Two pocket
model
One pocket
model
Feeding
methods
Auto Sheet Feeder:
You can put up to 100 documents in the ASF to
be fed automatically.
Sheet Feeder:
You need to put a document in
the SF one by one to be fed
automatically.
Processing
speed
30 dpm 60 dpm 90 dpm
——
Main pocket equipped equipped equipped equipped equipped
Sub pocket equipped equipped equipped equipped not equipped
For detailed information about processing speed, see "Processing speed" on page 18.
The specified processing speed is not achievable when using USB Full-Speed.

Epson TM-S1000 Specifications

General

Film scanning	No
Grayscale levels	256
Input color depth	- bit
Maximum scan size	120 x 235 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
Scan media weight	60 - 120 g/m²
Dimensions (WxDxH)	160 x 355 x 176 mm
Standard media sizes	Length: 120 mm - 235 mm (approx 4.8 in - 9 in), Height: 68mm - 120 mm (approx 2.7 in - 4.8 in), Thickness: 0.075 x 0.2 mm (approx 0.003 in - 0.008 in), Weight: 60 - 120 g/m2 (approx 16lb - 32lb)

Weight and Dimensions

Depth	355 mm
Width	160 mm
Height	176 mm
Weight	4000 g
