Epson TM-S1000 Technical Reference Guide

Chapter 1 Handling
45
4
Handling
This chapter describes basic handling of the scanner.
Turning On/Off
Press the power switch to turn the scanner on or off.
If the power switch cover is attached over the power switch, insert a pointed object into one
of the holes of the cover to press the switch.
Power switch
Power switch cover

Epson TM-S1000 Specifications

General

Film scanning	No
Grayscale levels	256
Input color depth	- bit
Maximum scan size	120 x 235 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
Scan media weight	60 - 120 g/m²
Dimensions (WxDxH)	160 x 355 x 176 mm
Standard media sizes	Length: 120 mm - 235 mm (approx 4.8 in - 9 in), Height: 68mm - 120 mm (approx 2.7 in - 4.8 in), Thickness: 0.075 x 0.2 mm (approx 0.003 in - 0.008 in), Weight: 60 - 120 g/m2 (approx 16lb - 32lb)

Weight and Dimensions

Depth	355 mm
Width	160 mm
Height	176 mm
Weight	4000 g
