Epson TM-S1000 Technical Reference Guide

Chapter 1 Handling
47
4
Opening the Franker Cover
Pull the franker cover open lever to open the franker lever.
Open the franker cover when you replace the franking cartridge with new one (See "Installing
and Replacing the Franking Cartridge" on page 48.) or remove jammed paper. (See "Removing a
Paper Jam" on page 57.)
Franker cover open lever

Epson TM-S1000 Specifications

General

Film scanning	No
Grayscale levels	256
Input color depth	- bit
Maximum scan size	120 x 235 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
Scan media weight	60 - 120 g/m²
Dimensions (WxDxH)	160 x 355 x 176 mm
Standard media sizes	Length: 120 mm - 235 mm (approx 4.8 in - 9 in), Height: 68mm - 120 mm (approx 2.7 in - 4.8 in), Thickness: 0.075 x 0.2 mm (approx 0.003 in - 0.008 in), Weight: 60 - 120 g/m2 (approx 16lb - 32lb)

Weight and Dimensions

Depth	355 mm
Width	160 mm
Height	176 mm
Weight	4000 g
