Epson TM-S1000 Technical Reference Guide

Chapter 1 Handling
53
4
For single feed models
1
Insert a document straight with its face (the side on which magnetic
characters are printed) facing outside into the SF, as shown in the picture
below.
2
After the document is automatically ejected to the Main/Sub pocket,
put the next document into the SF.
• Do not put more than one document in the SF. Otherwise, a paper jam or incorrect feed-
ing of multiple documents may result.
• Be sure to let go of the document before the scanner starts feeding. Otherwise, there
may be a paper skew, paper jam, or MICR reading error.
• Do not open the covers while processing is in progress.
1234780 1234567890
1234780 1234567890

Epson TM-S1000 Specifications

General

Film scanning	No
Grayscale levels	256
Input color depth	- bit
Maximum scan size	120 x 235 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
Scan media weight	60 - 120 g/m²
Dimensions (WxDxH)	160 x 355 x 176 mm
Standard media sizes	Length: 120 mm - 235 mm (approx 4.8 in - 9 in), Height: 68mm - 120 mm (approx 2.7 in - 4.8 in), Thickness: 0.075 x 0.2 mm (approx 0.003 in - 0.008 in), Weight: 60 - 120 g/m2 (approx 16lb - 32lb)

Weight and Dimensions

Depth	355 mm
Width	160 mm
Height	176 mm
Weight	4000 g
