Epson TM-T82X Technical Reference Guide

67
Appendix
Electrical Characteristics
Rated voltage/frequency 100 to 240VAC 50/60 Hz
Rated current 1.0 A
If printing is continuously performed with a high print ratio, the overcurrent protection may be
activated and result in uneven print density or a low voltage error. Therefore, the printing length
must not exceed the following values when printing with high print ratio.
Print ratio: Number of dots being energized per one dot line / Total number of dots per one dot line
(576 dots)
Print ratio 80% 100%
Print example
Print length 30 mm 20 mm
58 mm {2.28"}
72 mm {2.83"}

Epson TM-T82X Specifications

General

Print Method	Thermal line printing
Paper Width	80 mm
Autocutter	Yes
Power Supply	AC 100-240V, 50/60 Hz
Paper Roll Diameter	83 mm
Interface	USB, Ethernet
Dimensions	140 x 199 x 146 mm
Resolution	203 dpi x 203 dpi
