Epson TM T88IV Technical Reference Guide

Chapter 1 Product Overview
19
1
Error Status
There are three possible error types: automatically recoverable errors, recoverable errors, and
unrecoverable errors.
Automatically Recoverable Errors
Printing is n o longer possible when automatically recoverable errors occur. They can be
recovered easily, as described below.
Recoverable Errors
Printing is n o longer possible when recoverable errors occur. They can be recovered easily by
turning the power on again or sending an error recovery command from the driver after
eliminating the cause of the error.
Error Error description
Error LED flash code
Recovery measure
Roll paper
cover open
error
The roll paper cover
was opened during
printing.
Recovers automatically
when the roll paper
cover is closed.
Print head
temperature
error
A high temperature
outside the head drive
operating range was
detected.
Recovers automatically
when the print head
cools.
Error Error description
Error LED flash code
Recovery measure
Autocutter error Autocutter does not
work correctly.
Remove the jammed
paper or foreign matter
in the printer, close the
roll paper cover, send
the error recover
command, or turn the
power on to recover.
The error recovery command is valid only if a recoverable error (excluding automatically
recoverable errors) occurs.
Approx.
160 ms
Approx.
160 ms
Approx.2.56 s

Epson TM T88IV Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
Standard interfaces	Ethernet
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Type	POS printer
Character size	1.1 x 2.1 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL/CSA, TUV
Certification	CE, EN55022, EN55024, RoHS, WEEE
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, PDF417, UPC-A, UPC-E
Country of origin	China
Autocutter durability	1.5 million cuts
Mean time between failures (MTBF)	360000 h
Product color	White
Maximum roll diameter	83 mm
Supported paper width	72 mm
Operating temperature (T-T)	5 - 45 °C
Wi-Fi	No
Ethernet LAN	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Power supply type	DC
Pallet width	800 mm
Pallet height	1837 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Pallet height (UK)	2250 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2780 g
Quantity per pack	1 pc(s)
