Chapter 2 Setup
37
2
DIP Switch Bank 2
The transmission speed can be set with a command or the memory switch utility.
(Setting values: 2400, 4800, 9600, 19200, 38400, 57600, 115200) The value set with a
command or the memory switch utility is enabled only when DIP switches 1-7 and 1-8
are on. For other settings, the value set with the DIP switches is enabled.
Depending on print conditions such as print duty, print head temperature, and data
transmission speed, print speed is automatically adjusted, which can cause white lines
due to intermittent print (the motor sometimes stops). To avoid this, set the transmission
speed higher or keep the print speed constant by setting it lower. (See "Setting the
Memory Switches" on page 43.)
SW Function ON OFF
Factory
setting
2-1 Handshaking (BUSY condition) Receive buffer full
Offline
Receive buffer full
OFF
2-2
Reserved (Do not change
settings)
Fixed to OFF OFF
2-3
2-4
Selects print density/Low
power consumption mode
See "Selecting the Print Density (DIP Switch
2-3/2-4)" on page 41.
OFF
2-5
Setting the release condition
of the receive buffer BUSY
state (This function is effective
when DIP switch 1-2 is set to
off.)
Releases the BUSY
state when the
remaining capacity
of the receive
buffer reaches 138
bytes.
Releases the BUSY
state when the
remaining capacity
of the receive
buffer reaches 256
bytes.
OFF
2-6
Reserved (Do not change
settings)
Fixed to OFF OFF
2-7 I/F pin 6 reset signal Enabled Disabled OFF
2-8 IF pin 25 reset signal Enabled Disabled OFF
For DIP switch 2-1 (BUSY condition), see also "Selecting the BUSY Status" on page 42.
Do not change the setting of DIP switches 2-2 and 2-6. Otherwise, the printer may not
operate normally.
