Epson TM T88IV Technical Reference Guide

Chapter 1 Product Overview
21
1
NV Memory (Non-Volatile Memory)
The printer has NV memory which includes the user NV memory and NV graphics memory that
users can use.
NV Graphics Memory
Graphics such as shop logos to be printed on receipts can be stored. Even with a serial interface
model whose communication speed is low, high speed graphic printing is possible.
Use the TM Flash Logo Setup utility for NVRAM to register graphics.
NV Graphics Print Mode
In this mode the printer prints the following:
•Capacity of the NV graphics
•Used amount of the NV graphics
•Unused capacity of the NV graphics
•Number of the NV graphics that are registered
• Key code, number of dots in X direction, number of dots in Y direction, number of colors to be
defined.
•NV graphics dat
a
CAUTION
NV memory can be rewritten about 100,000 times. As a guide, NV memory rewriting should
be 10 times or less a day when you program applications.

Epson TM T88IV Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
Standard interfaces	Ethernet
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Type	POS printer
Character size	1.1 x 2.1 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL/CSA, TUV
Certification	CE, EN55022, EN55024, RoHS, WEEE
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, PDF417, UPC-A, UPC-E
Country of origin	China
Autocutter durability	1.5 million cuts
Mean time between failures (MTBF)	360000 h
Product color	White
Maximum roll diameter	83 mm
Supported paper width	72 mm
Operating temperature (T-T)	5 - 45 °C
Wi-Fi	No
Ethernet LAN	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Power supply type	DC
Pallet width	800 mm
Pallet height	1837 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Pallet height (UK)	2250 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2780 g
Quantity per pack	1 pc(s)
