Chapter 1 Product Overview
23
1
Product Specifications
Printing method Thermal line printing
Cutting method Partial cut (cutting with one point in left edge left uncut)
Roll paper (single-ply) Width: 79.5 ± 0.5 mm (3.13 ± 0.02")
Interface Serial (RS232C), Parallel (IEEE1284), LAN (10/100BASE-T),
USB (Full-speed), Wireless LAN (IEEE802.11b)
Buffer Receive buffer 4 KB/45 bytes (selectable using the DIP switch 1-2)
Downloaded buffer 12 KB (both for user-defined characters and downloaded images)
NV graphics data 256 KB
Barcode/two-dimensional
code printing
UPC-A, UPC-E
JAN 8 (EAN 8), JAN 13 (EAN 13)
CODE 39
ITF
CODABAR (NW-7)
CODE 93
CODE 128
PDF417
QR CODE
DKD Function 2 drives
Supplied voltage + 24 VDC ± 7%
Life Mechanism 15,000,000 lines
Thermal head 100 million pulses
Single-color printing: 100 km
Two-color printing: 50 km
Autocutter 1,5000,000 cuts
MTBF 360,000 hours
MCBF 52,000,000 lines
Temperature/humidity Operating: 5 to 45°C {41 to 113°F}, 10 to 90% RH
Storage: -10 to 50°C {14 to 122°F}, 10 to 90% RH
Overall dimensions 148 × 145 × 195 mm {5.83 × 5.71 × 7.68"} (H × W × D)
Weight (mass) Approx. 1.8 kg {3.96 lb} (Roll paper excluded)
