Epson TM T88IV

38
For Parallel/LAN/Wireless LAN Interface
DIP switch bank 1
DIP switch bank 2
SW Function ON OFF
Factory
setting
1-1 Auto line feed Always enabled Always disabled OFF
1-2 Receive buffer capacity 45 bytes 4 KB OFF
1-3
Selects paper sensors to
output paper-end signals
(default value of a command)
Disabled
Roll paper end
sensor enabled, roll
paper near-end
sensor enabled
OFF
1-4 Error signal output Disabled Enabled OFF
1-5 ∼
1-8
Undefined — — OFF
SW Function ON OFF
Factory
setting
2-1 Handshaking (BUSY condition) Receive buffer full
• Offline
• Receive buffer full
OFF
2-2
Reserved (Do not change
setting)
Fixed to OFF OFF
2-3 ∼
2-4
Selects print density/Low
power consumption mode
See "Selecting the Print Density (DIP Switch
2-3/2-4)" on page 41.
OFF
2-5
Setting the release condition
of the receive buffer BUSY
state (This function is effective
when DIP switch 1-2 is set to
off.)
Releases the BUSY
state when the
remaining capacity
of the receive
buffer reaches 138
bytes.
Releases the BUSY
state when the
remaining capacity
of the receive
buffer reaches 256
bytes.
OFF
2-6 ∼
2-7
Reserved (Do not change
settings)
Fixed to OFF OFF
2-8
IF pin 31 reset signal (Do not
change settings)
Fixed to ON ON
