Epson TM-U590 Technical Reference Guide

Chapter 1 Product Overview
17
1
Product Specifications
Printing method Serial impact dot matrix
Paper
feed
Paper feed method Friction feed
Paper feed pitch Default 4.23 mm {1/6"}
0.176 mm {1/144"} Units can be set by a command.
Interface Serial (RS232C), Parallel (IEEE1284)
Buffer Receive buffer 4 KB/69 bytes (selectable using the DIP switch 1-2)
Downloade buffer 5 KB (both for user-defined characters and downloaded images)
Ribbon Model ERC-31B
Life 4,500,000 characters (when 1 character = 18 dots)
DKD Function 2 drives
Power supply Optional PS-180 AC adapter
Life Mechanism 12,000,000 lines
Thermal head 200 million pulses (when printing Font B)
MTBF 180,000 hours
MCBF 29,000,000 lines
Temperature/humidity Operating: 5 to 45°C {41 to 113°F}, 10 to 90% RH
Storage: -10 to 50°C {14 to 122°F}, 10 to 90% RH
Overall dimensions (H × W × D) 185 × 252 × 266 mm {7.28 × 9.92 × 10.47"} (including the document
table)
Weight (mass) Approx. 5.0 kg {11.0 lb}

Epson TM-U590 Specifications

General

Color	No
Maximum number of copies	4 copies
Maximum print size	A4 (210 x 297 mm)
Media thickness	0.09 - 0.36 mm
Dimensions (WxDxH)	252 x 266 x 185 mm
Power requirements	24 DVC± 10%
Connectivity technology	Wired
Safety	UL / C-UL / TUV
Certification	VCC # 1, FCC class A, CE
Country of origin	China
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2600 mm
Quantity per pallet	6 pc(s)
Quantity per pallet (UK)	56 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	8 pc(s)
Package depth	333 mm
Package width	322 mm
Package height	253 mm
Package weight	5725 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	266 mm
Width	252 mm
Height	185 mm
